| Κατασκευαστής / Brand |
ASROCK |
| Κωδικός Προϊόντος (SKU) |
05-01-124-695 |
| Υποστηριζόμενοι Επεξεργαστές |
Supports AMD Socket AM4 Ryzen 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors |
| Chipset |
AMD A520 |
| Μέγεθος Μητρικής (Form Factor) |
mATX |
| Υποστήριξη Μνήμης RAM |
Dual Channel DDR4 Memory Technology. 4x DDR4 DIMM Sockets for non-ECC un-buffered DDR4 RAM up to 4533+(OC)MT/s. Max 128GB. Supports Extreme Memory Profile (XMP). 15μ Gold Contact in DIMM Slots |
| Κάρτα Γραφικών (GPU) |
Integrated AMD RADEON Vega Series graphics | 1 x HDMI 2.1 with max. resolution up to 4K x 2K (4096×2160) @ 60Hz, supports HDR, HDCP 2.3, 4K Ultra HD (UHD) playback | 1 x DisplayPort 1.4 with max. resolution up to 5K (5120×2880)@120Hz , supports HDCP 2.3, 4K Ultra HD (UHD) playback |
| Οθόνη & Ανάλυση |
1 x D-Sub with max. resolution up to 1920×1200 @ 60Hz |
| 2 x PCI Express 3.0 x16 Slots (PCIE1 |
x16 mode; PCIE2: x2 mode) |
| Αποθηκευτικός Χώρος (SSD/HDD) |
1 x M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module | 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1 and RAID 10), NCQ, AHCI and Hot Plug | 1 x Ultra M.2 Socket (M2_1), supports M Key type 2280 M.2 PCI Express module up to Gen3 x4 (32 Gb/s) | 1 x M.2 Socket (M2_2), supports M Key type 2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x2 (16 Gb/s) | ASRock Full Coverage M.2 Heatsink | ASRock Ultra M.2 (PCIe Gen3x4) |
| Συνδεσιμότητα / Θύρες |
PCIE x1 Gigabit LAN 10/100/1000 Mb/s | Supports Wake-On-LAN | Supports Lightning/ESD Protection | Supports Energy Efficient Ethernet 802.3az | Supports PXE | 1 x PS/2 Mouse/Keyboard Port (Rear) | 1 x D-Sub Port (Rear) | 1 x HDMI Port (Rear) | 1 x DisplayPort 1.4 (Rear) | 1 x USB 3.2 Gen1 Type-A Port (Supports ESD Protection) (Rear) | 4 x USB 3.2 Gen1 Type-A Ports (ASMedia ASM1074 hub) (Supports ESD Protection) (Rear) | 1 x USB 3.2 Gen1 Type-C Port (Supports ESD Protection) (Rear) | 2 x USB 2.0 Ports (Supports ESD Protection) (Rear) | 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) (Rear) | ASRock Full Spike Protection (for all USB, Audio, LAN Ports) |
| Χαρακτηριστικό 4 |
Realtek RTL8111H |
| Ήχος / Audio Codec |
7.1 CH HD Audio with Content Protection (Realtek ALC1220/ALC1200 Audio Codec) |
| Χαρακτηριστικό 5 |
Antenna Bracket (Rear) |
| HD Audio Jacks |
Line in / Front Speaker / Microphone. (Rear) |
| ASRock Super Alloy |
Premium 50A Power Choke, Sapphire Black PCB, High Density Glass Fabric PCB, 2oz Copper PCB |
| Χαρακτηριστικό 6 |
ASRock POST Status Checker (PSC) |
| Χαρακτηριστικό 7 |
ASRock Live Update & APP Shop |
| Πιστοποιήσεις |
FCC, CE, ErP/EuP |
| Εγγύηση |
3 χρόνια |
Παραλαβή απο το κατάστημα
